#Braumeister 200-litre
Think big
Portable - Compact - Automatic
The fully automatic brewing control takes over the brewing of individually adjusted recipes and runs through all brewing phases with exact times and temperatures. Lautering is done easily and quickly by lifting the malt pipe with the lifting device included. This way you can carry out the lautering process quickly and without mess.
In addition, the device is mobile and easy to move and the space requirement is minimal. This makes it ideal for restaurants, pubs, events or brewing communities. The low purchase cost and a lower price per litre ensure a short-term payback.
- Made of stainless steel
- Quantity: 200 l of finished beer (normal beer) = approx. 230 l of wort
- Max. malt quantity 42 kg
The new touchscreen control
The new automatic control system brews with your own individual recipes and guides you through the brewing process. Recipes and software updates can be synced automaticaly with the integrated wifi. The time and temperature are precisely maintained through all brewing phases. The new touchscreen makes it even easier to operate the Braumeister.
In addition, the large Braumeisters have integrated a new pressure sensor-controlled pump control. The pressure sensor in the pressure line which is connected with the malt pipe allows you to regulate the pump speed via the pressure. The new timer function saves time because, for example, the brewing water can be heated up early in the morning.
Advantages
- New control system with touch screen, integrated brewing guide and Wifi for software updates and sync of recipes
- Pressure sensor controlled pump regulation
Control software:
- Brewing guide - shows also quantity and kind of raw materials
- Precise temperature measuring
- Help informations in the brewing process
- Pump pauses are adjustable
- Integrated Wifi for software updates over the air and sync of recipes with MySpeidel
- Integrated data base of raw materials
- Timer function - for time delayed brew start
- Ferment control allows data of the Tilt-Hydrometer
Control hardware:
- IP 65 water resistant
- Touchscreen 5"
- Additional connections 24V and CAN for future accessories
- Wifi and Bluetooth integrated
Technical details
- Heating coil: 3 x 3.000 W output
- Pump: 370 WPower supply connection: 400 V
(fuse protection min. 16 Amp) - Total power consumption: 10 kW
- Cooling: 1.3 m2 double jacket surface area,
with ice water, approximately 50 min to 25 °C with whirlpool - Control system fully automatic brewing control
(temperature, time, pump) - Max. malt quantity: 42 kg
Dimensions
- Length: 136 cm
- Width: 90 cm
- Height: 210 cm
- Wooden crate: 132 x 100 x 175 cm (length x width x height)
- Shipping weight: 200 kg
weight 150,00 kg
Stock
Product.Nr. 45200-20
